Inconel Alloy Wire
- Product Item : CP-004
- Category： Metal Wires
- Product description：Inconel Alloy Wires - Inconel600 / Incoloy825 Soft Wire Diameter Range: 0.08-2.00mm
Soft Wire Diameter Range: 0.08-2.00mm
Tolerance and Roundness: (According to GB/TS21653-2008)
|
Diameter（mm） |
0.08-0.10 |
>0.10-0.40 |
>0.40-0.80 |
>0.80-1.20 |
>1.20-2.0 |
|
Tolerance(mm) |
±0.005 |
±0.006 |
±0.013 |
±0.02 |
±0.03 |
|
Roundness(mm) |
0.005 |
0.006 |
0.013 |
0.02 |
0.03 |
Inconel 600, UNS N06600, EN2.4816, Cr15Ni75Fe8
Applications: Heat treatment and chemical processing fields.
Characteristics: Resistance to corrosion from high temperature oxides, good mechanical properties under high temperature.
Chemical Compositions: (According to GB/TS5235-2007)
|
Ni |
Cr |
Fe |
C |
Mn |
S |
Cu |
Si |
|
Balance |
14-17 |
6.0-10.0 |
≤0.15 |
≤1.00 |
≤0.015 |
≤0.50 |
≤0.50 |
Mechanical Properties: (According to GB/T21653-2008)
|
Temper |
Diameter(mm) |
Tensile Strength(N/mm2) |
Elongation（%） |
|
Soft |
0.2-0.5 |
≥390 |
≥20 |
|
0.5-1.0 |
≥370 |
≥25 |
|
|
1.0-2.0 |
≥585 |
≥30 |
Incoloy 825, UNS N08825, EN2.4858, 0Cr21Ni42Mo3Cu2Ti
Applications: Heat Exchangers and condensers, also in sulfuric acid environment with rich ions.
Characteristics: Good resistance to stress corrosions and redox(oxidation-reduction) corrosions, good mechanical
properties from room temperature to 550℃.
Chemical Compositions: (According to GB/TS5235-2007)
|
C |
Cr |
Ni |
Fe |
Mo |
Cu |
Al |
Ti |
Si |
Mn |
P |
S |
|
≤0.05 |
19-23.5 |
38.0- 46.0 |
Surplus |
2.5-3.5 |
1.5-3.0 |
≤0.20
|
0.60- 1.20 |
≤0.50 |
≤1.00 |
≤0.03 |
≤0.03 |
Mechanical Properties: (According to GB/T21653-2008)
|
Temper |
Diameter(mm) |
Tensile Strength(N/mm2) |
Elongation（%） |
|
Soft |
0.2-0.5 |
≥390 |
≥20 |
|
0.5-1.0 |
≥370 |
≥25 |
|
|
1.0-2.0 |
≥585 |
≥30 |
